| Place of Origin: | BEIJING,CHINA |
|---|---|
| Brand Name: | GFUVE |
| Model Number: | GF312D1 |
| Minimum Order Quantity: | 1 SET |
| Packaging Details: | CARTON |
| Delivery Time: | 1-2WEEKS |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 1500SETS/MONTH |
| ACCURACY: | 0.05%, 0.1% | MEASURING MODE: | DIRECT CONNECTION AND CLAMP |
|---|---|---|---|
| DISPLAY: | 6”TFT (640×480) | TEST RANGE: | 0-480V,0-12A |
| WEIGHT: | 1.8KG | DIMENSION: | 245×162×60MM |
| POWER SUPPPLY: | 220V±10%, 50/60Hz | ||
| High Light: | 480V Meter Calibration Equipment,TFT Meter Calibration Equipment,IEC 60736 Meter Calibration Equipment |
||
FEATURES
TECHINICAL PARAMETERS
| Phase angle | |
|---|---|
| Range | 0°-360° |
| Resolution | 0.01o |
| Frequency | ||
|---|---|---|
|
Range |
40-70Hz | |
| Resolution | 0.001Hz | |
| Function | |
|---|---|
| Vector diagram | Yes |
| Waveform | Yes |
| Energy accumulation | Yes |
| Communication with PC | Yes |
| Overload protection | Yes |
| Standard | |
|---|---|
| lsolation protection | IEC 61010-1:2001 |
| Energy measurement | IEC 60736 |
| Reference standard | IEC 62052-11 IEC62053-21 IEC62053-22 & IEC62053-23 IEC61010-1:2001 |
| Calibration and maintenance | ||
|---|---|---|
| Warranty | 5 years | |
| Calibration | Lifelong free calibration service | |
| Recommended calibration interval | Every two years | |
