Beijing GFUVE Instrument Transformer Manufacturer Co.,Ltd.
an exclusive current transformer, split core current transformer, current clamp & voltage transformer manufacturer.
| Place of Origin: | BEIJING,CHINA |
|---|---|
| Brand Name: | GFUVE |
| Model Number: | GF312V2 |
| Minimum Order Quantity: | 1SET |
| Packaging Details: | CARTON |
| Delivery Time: | 1-2WEEKS |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 1500SETS/MONTH |
| ACCURACY: | 0.05%, 0.1% | POWER SUPPLY: | External Power, 220V/110V, 50/60Hz |
|---|---|---|---|
| VOLTAGE: | 30-560V | HARMONIC: | 2nd-51st |
| CURRENT: | 0.01-10A | FREQUENCY: | 45Hz-65Hz |
| RESOLUTION: | 7” TFT Color (480×234) | FUNCTION: | Screen Printing,Wiring EmulationExternal Keyboard |
| Ambient Temperature: | -25°C To +45°C | DIMENSION: | 245×168×70MM |
| WEIGHT: | 1.8 KG | ||
| High Light: | Multifunctional Test Meter Calibration,10A Test Meter Calibration,Screen Printing Electric Meter Calibration |
||
FEATURES
TECHNICAL PARAMETERS
| Electrical parameters | |
|---|---|
| Accuracy class | 0.05%, 0.1% |
| Power Supply | External power, 220V/110V, 50/60Hz Phase voltage supply 45-450V, 50/60Hz Li-Battery supply |
| Voltage measurement | |
| Range | 30-560V |
| Error | ±0.05% |
| Harmonic | 2nd-51st |
| Current measurement | |
| Range (direct connection) | 0.01-10A |
| Range (clamp CT) | 5A,100A,500A,1000A,2000A (option) |
| Error (direct connection) | ±0.05% |
| Error (clamp CT) | ±0.2% (5A, 100A ) ±0.5% (other) |
| Harmonic | 2nd-51st |
| Power measure error | |
| Active power (direct connection) | ±0.05% |
| Active power (clamp CT) | ±0.2% (5A, 100A) ±0.5% (other) |
| Reactive power (direct connection) | ±0.1% |
| Reactive power (clamp CT) | ±0.2% (5A, 100A) ±0.5% (other) |
| Energy measure error | |
| Active energy (direct connection) | ±0.05% |
| Active energy (clamp CT) | ±0.2% (5A, 100A) ±0.5% (other) |
| Reactive energy (direct connection) | ±0.1% |
| Reactive energy (clamp CT) | ±0.2% (5A, 100A) ±0.5% (other) |
| Phase angle | |
| Range | 0°-360° |
| Resolution | 0.01° |
| Error | ±0.05° |
| Frequency | |
| Range | 45Hz-65Hz |
| Resolution | 0.001Hz |
| Error | 0.002Hz |
| Pulse output | |
| Energy constant | 25000 |
| Pulse ratio | 1:1 |
| Output level | 5V |
| Pulse input | |
| Input channel | 2 |
| Input level | 5-10V |
| Input frequency | Max. 100Hz |
| Display | |
| Resolution | 7” TFT color (480×234) |
| Function | |
| Vector diagram | Yes |
| Waveform | Yes |
| Energy accumulation | Yes |
| CT ratio test | Yes |
| Local parameter input | Yes |
| Wiring emulation | Yes |
| Self-calibration | Yes |
| Recorder check | Yes |
| Data storage | Yes |
| Data storage qty | 5000 |
| External extend memory | Yes |
| Screen printing | Yes |
| Communication port | USB/RS232 |
| Communication with PC | Yes |
| Upload data | Yes |
| External mini printer | Yes |
| External keyboard | Yes |
| Mechanical parameters | |
| Dimensions (W×H×D) (mm) | 245×168×70 |
| Weight (kg) | 1.8 |
| Environmental conditions | |
| Ambient temperature | -25°C to +45°C |
| Relative humidity | 30%-95% |
